Product description
Yongli aquatic weed harvester/water hyacinth cutting ship/trash skimmer/garbage collection boat/surface cleaning boat is a kind of equipment for cleaning aquatic plants such as water weeds, trash skimmer,duckweed, water hyacinth and floating domestic garbage.
When working, the hydraulic cylinder is controlled by the hydraulic system to lower the front collection tank below the water surface. The most front bottom shear starts to work under the drive of the hydraulic motor, and its main function is to cut the root of the water grass. There are two circular saw blades on both sides of our collection pod, which are driven by hydraulic motor to turn rapidly respectively.
Sharp saw blades are the key to cutting transverse aquatic plants, which can not only cut off the branches quickly, but also clear the path for cleaning the ship. The saw blades and the bottom scissors cooperate with each other to carry out the first step of cutting and collecting. Next to the bottom shear is the collection chain in the front cabin. Driven by the motor, the collection chain starts to rotate and transfer the cut water weeds to the storage cabin, thus completing the collection work. When the water weeds or floating objects fill the middle and rear compartments, the ship can drive to the shore to unload the materials. Start the chain in the rear cabin to run quickly, unload the water grass or floating material to the shore, so that a job is completed, and the water cleaning ship is driven back to the work site for cycle working. Automatic cleaning ship is currently the most widely used, according to the different plants on the water, can be used for cleaning ship supporting different parts, such as saw blade, bottom shear, vertical shear, wheel knife, etc., according to the water area is different, the design meets the requirements of the hull size, some complex waters can also be used with several cleaning ships, wish our cleaning ship can protect our green mountains to contribute.
Parameter
Model | YLWH-120 | YLWH-160 | YLWH-180 | YLWH-200 | YLWH-220 |
Size (L*W*H) | 7x2.3x1.6 m | 10.5*4.2*2.5 m | 12*4.4*2.7 m | 15*4.5*2.7 m | 17*4.5*4 m |
Cutting Width (m) | 1.2 m | 1.6m | 1.8m | 2m | 2.2m |
Cutting Depth (m) | 0.5 m | 0.8m | 1m | 1.1m | 1.2m |
Draft (m) | 0.4-0.5 m | 0.4-0.5 m | 0.4-0.5 m | 0.4-0.5 m | 0.4-0.5 m |
Discharge Height (m) | 1.5 m | 2.5 m | 2.5 m | 2.5 m | 2.5 m |
Driven Type | Paddle wheel | Paddle wheel | Paddle wheel | Paddle wheel | Paddle wheel |
Control System | Semi Automatic | Full Hydraulic | Full Hydraulic | Full Hydraulic | Full Hydraulic |
Features
1.Easy operation.
One person can operate in the operation room to control the machine forward and backward and steering.
The machine movement can be all hydraulic controlled with low consumption, discharge time is within 2 minutes.
3.Cost-Effective
Large bearing capacity, stable transmission and few failure rate.
Application
Company profile
Qingzhou Yongli Mining And Dredging Machinery Co., Ltd , is one of China leading company of sand & gold & diamond mining equipments,aquatic weed harvester/water hyacinth cutting ship/trash skimmer/garbage collection boat/surface cleaning boat which has more than 25 years' experience in designing,producing ,manufacturing and selling cutter suction dredgers, jet suction dredgers,bucket chain dredger, diamond/gold dredgers, pulsating sluice box, sand/ gold washing plant, sand washing & screening machinery, transport barge,work boat, amphibious multi-functional dredger,aquatic weed harvester/water hyacinth cutting ship/trash skimmer/garbage collection boat/surface cleaning boat and so on. Successful series of products have won the recognization and approval of general administration of Quality Supervision. Now our company's products are widely exported and used in the Russia,South Africa,South, Middle East, India, Kyrgyzstan and other regions.
