1. Product Information
Latest we are producing one set of 600 tons cargo carrying transport barge. This 600 tons capacity transport barge will be used for transporting the shipping containers and bulk cargo goods.
Here below are the detailed technical specification of 600 tons cargo transport barge:
Item | Specification |
Description of Cargo Transport Barge | YLTB-600 China Transport Barge |
1. Dimension of Transport Barge | |
1) Hull length | 50m |
2) Hull breadth | 9m |
3) Hull height | 3.2m |
4) Total height | 10.3m(including living room and operation cabin) |
5) Bottom steel plate | 8mm |
6) Side steel plate | 8mm |
7) Deck steel plate | 10mm |
2. Diesel engine of China transport barge | |
1) Manufacturer | Weichai |
2) Model | WP13C450-18E220 |
3) Power | 330KW |
4) Speed | 1800r/min |
5) Amount | 2 sets |
3. Gearbox of China transport barge | |
1) Manufacturer | Hangzhou Fada |
2) Model | FD345 |
3) Ratio | 3:1 |
4) Amount | 2 sets |
4. Self-propelled system of China transport barge | |
1) Shaft diameter | 125mm |
2) Propeller diameter | 1.5m |
3) Hydraulic steering machine | 3 tons |
5. Diesel generator set of cargo transport barge | |
1) Manufacturer | Weichai |
2) Power | 50kw |
6. Toilet | 4 units |
7. Transport volumes per time | 600 tons per time |
8. Navigation speed of transport barge price | 8-10 knots |
9. The 1st Floor (2m height) | Six rooms (four living rooms,one dining room & one kitchen); one outside toilet with shower. |
10. The 2nd Floor (2m height) | Six living rooms; one outside toilet with shower. |
11. The 3rd Floor (2m height) | Two living rooms(each one toilet and shower inside) One office |
12. Operation Cabin of transport barge price | Total 1.1m higher than 3rd floor (including the window sill) |
2.Request for reply
1) How many tons of transport capacity do you need for this cargo transport barge ?
2) what kind of goods or cargo will you use this transport barge to transport?
3) will you use this cargo transport barge in the river,lake or sea?
4）For the engine brand of this cargo transport barge,will you choose weichai or cummins?
5) If you need the classfication society certificate for this China transport barge?
6) what is your required speed for this China transport barge please?
